2024 Live Wire Complete
2024 Live Wire Complete
Couldn't load pickup availability
Description
Description
The Live Wire Titanium Hardtail is a premium, trail-hungry frame, meticulously handcrafted in Chattanooga, Tennessee from 3AL/2.5V aerospace-grade titanium.
Designed to blend lateral stiffness with all-day comfort, this frame is engineered for hard-charging trail performance; quick to accelerate, smooth over rough terrain, and built to last a lifetime.
With modern geometry optimized for 130–140mm travel forks and short stems, the Live Wire offers sharp handling, excellent body position, and confident cornering on tight switchbacks and technical terrain.
It's fast, responsive, and built to dominate technical singletrack, big climbs, and rowdy descents. Ideal for performance-focused riders who value strength, precision handling, and a bike that brings joy and confidence to every ride. Whether you’re tackling aggressive terrain or ripping flow trails, the Live Wire delivers a ride that’s nimble, tough, and timeless.
Key Features
Key Features
- Performance Hardtail Geometry
- 3AL/2.5V Titanium Tubeset
- Up to 29 x 2.5" or 27.5 x 3.0" tires
- 31.6mm seatpost diameter
- 1x Drivetrain Specific
- 148mm Rear Boost Spacing
- External Cable Routing
- IS42/52 Tapered Headtube
- 73mm BSA English Threaded Bottom Bracket
microSHIFT Advent X 1x10
microSHIFT Advent X 1x10
| microSHIFT Advent X 1x10 | Component |
|---|---|
| Shift Lever | microShift Advent X Trail Pro |
| Lever/Brakeset | Shimano BL-MT201 lever and caliper |
| Brake Adaptor | POST Mount BRACKET – Flat mount to Post mount |
| Brake Rotors | Shimano Disc Brake Rotor |
| Rear Derailleur | microSHIFT Advent X V2 |
| Cassette | microSHIFT Advent X 11-48t |
| Crankset | Shimano Cues 30t |
| Chain | Shimano CN-HG54 10 speed |
| Bottom Bracket | Shimano BB-MT501 |
| Fork | Cane Creek Helm MKII 130mm |
| Wheelset | FSA Afterburner 29er |
| Tire | Kenda 29x2.4” |
| Handlebar | Afterburner Low Rise 31.8mm clamp |
| Grip | Ritchey True Grip |
| Stem | FSA alloy |
| Headset | Cane Creek 40, IS42|52 |
| Seat Post | FSA alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
Shimano Deore 1x12
Shimano Deore 1x12
| Shimano Deore | Component |
|---|---|
| Shift Lever | Shimano Deore Shifter |
| Lever/Brakeset | Shimano Deore Disc Brake |
| Brake Adaptor | POST Mount BRACKET – Flat mount to Post mount |
| Brake Rotors | Shimano Disc Brake Rotor |
| Rear Derailleur | Shimano SLX RD-M7100 SGS |
| Cassette | Shimano Deore CS-M6100 10-51t |
| Crankset | Shimano Deore Crankset |
| Chain | Shimano CN-M6100 QL |
| Bottom Bracket | Shimano BB-MT801 |
| Fork | Cane Creek Helm MKII 130mm |
| Wheelset | Shimano WH-MT620 29er |
| Tire | Kenda 29x2.4” |
| Handlebar | Afterburner Low Rise 31.8mm clamp |
| Grip | Ritchey True Grip |
| Stem | FSA alloy |
| Headset | Cane Creek 40, IS42|52 |
| Seat Post | FSA alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
Shimano XT Di2 Wireless
Shimano XT Di2 Wireless
| Shimano XT Wireless | Component |
|---|---|
| Shift Lever | Shimano XT Shift Switch |
| Lever/Brakeset | Shimano XT Brakes |
| Brake Adaptor | POST Mount BRACKET – Flat mount to Post mount |
| Brake Rotors | Shimano Disc Brake Rotor |
| Rear Derailleur | Shimano XT RD-M8100 SGS |
| Cassette | Shimano XT CS-M8200 10-51t |
| Crankset | Shimano XT FC-M8200 |
| Chain | Shimano XT |
| Bottom Bracket | Shimano BB-MT801 |
| Fork | Cane Creek Helm MKII 130mm |
| Wheelset | Shimano WH-MT620 29er |
| Tire | Kenda 29x2.4” |
| Handlebar | Afterburner Low Rise 31.8mm clamp |
| Grip | Ritchey True Grip |
| Stem | FSA alloy |
| Headset | Cane Creek 40, IS42|52 |
| Seat Post | FSA alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
Shipping
Shipping
Our unassembled shipping selection will arrive to you with the bottom bracket installed in the frame and the crown race installed on the fork. All other parts will be off of the bike and need to be fully installed and setup.
Our assembled shipping (for US customers) will be built up here at the factory and tested before shipping out to you. This will arrive to you with the front wheel removed from the fork, the handlebars out of the stem and and tucked next to the frame, and the seat/seat post removed from the frame.
Sizing/Geometry
Sizing/Geometry
Please refer to our geometry chart below for detailed sizing specifications.
You can select your preferred size when placing your order, and if you have any questions about fit, don’t hesitate to reach out. We’re happy to walk you through the details and can adjust your order if needed.
If you’re between sizes and seeking a more comfortable, long-distance fit, we typically recommend sizing up. This will give you a taller stack height and a slightly more upright riding position for added comfort.
If you prefer a racier, more performance-oriented fit, opt for the smaller size for a more compact and agile feel.
| Live Wire Geometry | SM | MD | LG | XL |
|---|---|---|---|---|
| Rec. Height Domestic | 5"3"-5'5" | 5'6"-5'9" | 5'10"-6'2" | 6'3"+ |
| Rec. Height International | 160-169 | 170-179 | 180-188 | 190+ |
| Seat Tube Length | 375 | 410 | 455 | 505 |
| ETT (Effective Top Tube) | 599 | 619 | 645 | 679 |
| Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
| Seat Tube Angle | 74 | 74 | 74 | 74 |
| BB Drop | 61 | 61 | 61 | 61 |
| Chain Stay Length | 445 | 445 | 445 | 445 |
| Head Tube Length | 111 | 111 | 116 | 120 |
| Rake | 44 | 44 | 44 | 44 |
| Standover Height | 711 | 736 | 769 | 812 |
| Wheelbase | 1165 | 1185 | 1210 | 1244 |
| Front Center | 727 | 747 | 773 | 806 |
| Stack | 648 | 648 | 652 | 656 |
| Reach | 414 | 434 | 458 | 490 |
| Frame Weight (lbs.) | 4.1 | 4.2 | 4.3 | 4.4 |
