Meraki Complete Bike
Meraki Complete Bike
Couldn't load pickup availability
Description
Description
Born from passion, crafted with purpose—Meraki is a titanium road bike that reflects the spirit of its rider. Named for the Greek word meaning “to do something with soul, creativity, and love,” Meraki isn’t just a bike—it’s a personal expression in motion.
Every weld, every curve, every line is a testament to meticulous craftsmanship and timeless design. The titanium frame offers a perfect harmony of strength, lightness, and ride quality—responsive when you demand speed, forgiving when the miles stretch long.
Whether you're chasing sunrise on quiet roads or carving corners on a fast descent, Meraki transforms every ride into a moment of connection—between rider, machine, and the road ahead.
Key Features
Key Features
- Performance engineered 3AL-2.5V tubeset for responsiveness, stability, durability, and comfort
- 1.75" bi-ovalized and Helix twisted downtube for ultimate power transfer while retaining compliance
- Squared 1.5" top tube for better steering response
- 27.2mm seat post
- Internal Cable Routing
- (2) water bottle mounts
- Tapered Headtube
- 68mm English Threaded BSA Bottom Bracket Shell
- Conquer any mixed terrain with clearance for 700c x 32c tires
- UDH compatible dropouts
Shimano 105 2x12 Mechanical
Shimano 105 2x12 Mechanical
| Shimano 105 2x12 | Component |
|---|---|
| Lever/Brakeset | Shimano 105 R7120 Shifter/Brake Set |
| Brake Rotors | Shimano Brake Rotors |
| Rear Derailleur | 105 R7100 12 speed |
| Front Derailleur | 105 R7100 34.9mm Band Clamp |
| Cassette | 105 HG710 12 speed 11-36t |
| Crankset | 105 R7100 50/34t |
| Chain | Shimano M6100 12 speed |
| Bottom Bracket | Shimano SM-BBR60 |
| Fork | Speeder Road Disc Fork |
| Wheelset | Shimano RX180 700c |
| Tire | Kenda 700x30c |
| Handlebar | FSA Alloy Bar |
| Grip | Lynskey Bar Tape |
| Stem | FSA alloy |
| Headset | Cane Creek 40 IS42/52 |
| Seat Post | FSA alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
Shimano 105 Di2 2x12
Shimano 105 Di2 2x12
| Shimano 105 Di2 2x12 | Component |
|---|---|
| Lever/Brakeset | Shimano 105 R7170 Shifter/Brake Set |
| Brake Rotors | Shimano Brake Rotors |
| Rear Derailleur | 105 R7150 Di2 12 speed |
| Front Derailleur | 105 R7150 Di2 34.9mm Band Clamp |
| Cassette | 105 HG710 12 speed 11-36t |
| Crankset | 105 R7100 50/34t |
| Chain | Shimano M6100 12 speed |
| Bottom Bracket | Shimano SM-BBR60 |
| Di2 Cable | E-Tube Wire 1400mm |
| Di2 Cable | E-Tube Wire 800mm |
| Di2 Frame Grommet | E-tube frame grommets – 6mm round |
| Di2 Battery Charger | EC300A Charging Cable |
| Di2 Battery | BT-DN300 Internal Battery |
| Battery Mount | Ritchey Di2 Seat post Mount |
| Fork | Speeder Road Disc Fork |
| Wheelset | Shimano RX180 700c |
| Tire | Kenda 700x30c |
| Handlebar | FSA Alloy Bar |
| Grip | Lynskey Bar Tape |
| Stem | FSA alloy |
| Headset | Cane Creek 40 IS42/52 |
| Seat Post | FSA alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
Shimano Ultegra Di2 2x12
Shimano Ultegra Di2 2x12
| Shimano Ultegra Di2 2x12 | Component |
|---|---|
| Lever/Brakeset | Shimano Ultegra R8170 Shifter/Brake Set |
| Brake Rotors | Shimano Brake Rotors |
| Rear Derailleur | Ultegra R8150 Di2 12 speed |
| Front Derailleur | Ultegra R8150 Di2 34.9mm Band Clamp |
| Cassette | Ultegra HG8100 12 speed 11-34t |
| Crankset | Ultegra R8100 50/34t |
| Chain | Shimano M8100 12 speed |
| Bottom Bracket | Shimano SM-BBR60 |
| Di2 Cable | E-Tube Wire 1400mm |
| Di2 Cable | E-Tube Wire 800mm |
| Di2 Frame Grommet | E-tube frame grommets – 6mm round |
| Di2 Battery Charger | EC300A Charging Cable |
| Di2 Battery | BT-DN300 Internal Battery |
| Battery Mount | Ritchey Di2 Seat post Mount |
| Fork | Speeder Road Disc Fork |
| Wheelset | Shimano RX180 700c |
| Tire | Kenda 700x30c |
| Handlebar | FSA Alloy Bar |
| Grip | Lynskey Bar Tape |
| Stem | FSA alloy |
| Headset | Cane Creek 40 IS42/52 |
| Seat Post | FSA alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
SRAM Rival AXS 2x12
SRAM Rival AXS 2x12
| SRAM Rival AXS 2x12 E1 | Component |
|---|---|
| Lever/Brakeset | SRAM Rival eTap AXS HRD E1 Shifter w/Caliper |
| Brake Rotors | SRAM Centerline 160mm Rotor - Center Lock |
| Rear Derailleur | SRAM Rival eTap AXS E1 Rear Derailleur - 36t Max |
| Front Derailleur | SRAM Rival eTap AXS E1 Front Derailleur |
| Braze-on Adaptor | SRAM Braze-on Front Derailleur Clamp: 34.9mm |
| Cassette | SRAM XG-1250 12-SPEED CASSETTE 10-36t |
| Crankset | SRAM Rival AXS 2x12-SPD Crankset E1 |
| Chain | SRAM Rival D1 Flattop 12 Speed Chain |
| Bottom Bracket | SRAM DUB Bottom Bracket - BSA 68mm English threaded |
| Battery | SRAM eTap Battery |
| SRAM charger | SRAM eTap Battery Charger and Cord |
| Fork | Speeder #5 Road Disc Fork |
| Wheelset | Vision Team 30 |
| Tire | Kenda 700x30c |
| Handlebar | FSA Alloy |
| Bar Tape | Lynskey Bar Tape - Blk |
| Stem | FSA Alloy |
| Headset | FSA Orbit C-40 Headset, IS42|52 |
| Compression Plug | FSA Compression Plug |
| Seat Post | FSA Alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
SRAM Force AXS 2x12
SRAM Force AXS 2x12
| SRAM Force AXS 2x E1 | Component |
|---|---|
| Lever/Brakeset | SRAM Force eTap AXS E1 HRD Shifter w/Caliper |
| Brake Rotors | SRAM 160mm Rotor, Centerlock |
| Rear Derailleur | SRAM Force eTap AXS E1 Rear Derailleur - 36t Max |
| Front Derailleur | SRAM Force eTap AXS E1 Front Derailleur |
| Braze-on Adaptor | SRAM Braze-on Front Derailleur Clamp: 34.9mm |
| Cassette | SRAM XG-1270 12-SPEED CASSETTE 10-36t |
| Crankset | SRAM Force AXS 2x12-SPD Crankset E1 |
| Chain | SRAM Force D1 Flattop 12 Speed Chain |
| Bottom Bracket | SRAM DUB Bottom Bracket - BSA 68mm English threaded |
| Battery | SRAM eTap Battery |
| SRAM charger | SRAM eTap Battery Charger and Cord |
| Fork | Speeder #5 Road Disc Fork |
| Wheelset | Vision Team 30 |
| Tire | Kenda 700x30c |
| Handlebar | FSA Alloy |
| Bar Tape | Lynskey Bar Tape - Blk |
| Stem | FSA Alloy |
| Headset | FSA Orbit C-40 Headset, IS42|52 |
| Compression Plug | FSA Compression Plug |
| Seat Post | FSA Alloy |
| Saddle | Lynskey Pro Saddle - Blk |
| Note | ***All parts subject to change based on availability with similar products*** |
Shipping
Shipping
Our unassembled shipping selection will arrive to you with the bottom bracket installed in the frame and the crown race installed on the fork. All other parts will be off of the bike and need to be fully installed and setup.
Our assembled shipping (for US customers) will be built up here at the factory and tested before shipping out to you. This will arrive to you with the front wheel removed from the fork, the handlebars out of the stem and and tucked next to the frame, and the seat/seat post removed from the frame.
Sizing/Geometry
Sizing/Geometry
Please refer to our geometry chart below for detailed sizing specifications.
You can select your preferred size when placing your order, and if you have any questions about fit, don’t hesitate to reach out. We’re happy to walk you through the details and can adjust your order if needed.
If you’re between sizes and seeking a more comfortable, long-distance fit, we typically recommend sizing up. This will give you a taller stack height and a slightly more upright riding position for added comfort.
If you prefer a racier, more performance-oriented fit, opt for the smaller size for a more compact and agile feel.
| Meraki Geometry | XS | SM | MD | ML | LG | XL |
|---|---|---|---|---|---|---|
| Rec. Height Domestic | 5"0"-5'2" | 5"3"-5'5" | 5'6"-5'8" | 5'9"-5’11" | 6’0”-6’2” | 6'3"+ |
| Rec. Height International | 152cm-157cm | 160cm-165cm | 168cm-173cm | 175cm-180cm | 183cm-188cm | 190cm+ |
| Seat Tube Length | 460 | 480 | 500 | 520 | 540 | 560 |
| ETT (Effective Top Tube) | 498 | 520 | 544 | 558 | 577 | 593 |
| Head Tube Angle | 70.5 | 71 | 71.5 | 71.5 | 73.5 | 73.5 |
| Seat Tube Angle | 75.5 | 74.5 | 74 | 73.5 | 73.5 | 73.5 |
| BB Drop | 75 | 75 | 75 | 75 | 74.5 | 74 |
| Chain Stay Length | 415 | 415 | 415 | 415 | 415 | 415 |
| Head Tube Length | 120 | 140 | 160 | 180 | 198 | 218 |
| Rake | 45 | 45 | 45 | 45 | 45 | 45 |
| Standover Height | 738 | 750 | 770 | 806 | 830 | 840 |
| Wheelbase | 977 | 985 | 1016 | 1031 | 1044 | 1054 |
| Front Center | 574 | 583 | 598 | 613 | 627 | 638 |
| Stack | 520 | 541 | 561 | 580 | 597 | 617 |
| Reach | 364 | 374 | 383 | 392 | 400 | 410 |
| Frame Weight (lbs.) | 3.3 | 3.4 | 3.5 | 3.6 | 3.7 | 3.8 |
