Description
Description
These Olympus frames are done and ready to box and ship. We have a small selection of each size with graphics already applied. Hurry because these won't last long. Frames will come with the seat post clamp, rear axle, and a brass head tube badge.
The Olympus all-mountain hardtail is a high-performance titanium frame designed for riders who crave durability, precision, and a smooth ride across rugged trails. It blends the lightweight strength and natural flex of titanium, offering a responsive yet forgiving ride, even on the most challenging terrain.
Ideal for riders who want the best of both worlds: the efficiency and directness of a hardtail with the durability, comfort, and smoothness of titanium. Whether you're descending rocky ridgelines or climbing technical switchbacks, the Olympus delivers a ride that inspires confidence.
Key Features
Key Features
- 29 x 2.5" tire clearance
- 31.6mm seat post
- 38.1mm seat tube clamp
- UDH ready dropouts
- 1-1/8"-1-1/2" tapered headtube
- IS42/IS52 headset fitment
- 12 x 148mm rear hub spacing
- 73mm BSA English Threaded Bottom Bracket
- Tuned for a 140mm travel fork
- single bottle cage mount on down tube
- 160mm-180mm rear rotor
- Frame mount for rear brake is flat mount but can be fit with post mount with adapter
Shipping
Shipping
Our goal is to have your frame order shipping out to you within 10 business days from the date of your order.
Sizing/Geometry
Sizing/Geometry
Please refer to our geometry chart below for detailed sizing specifications.
You can select your preferred size when placing your order, and if you have any questions about fit, don’t hesitate to reach out. We’re happy to walk you through the details and can adjust your order if needed.
If you’re between sizes and seeking a more comfortable, long-distance fit, we typically recommend sizing up. This will give you a taller stack height and a slightly more upright riding position for added comfort.
If you prefer a racier, more performance-oriented fit, opt for the smaller size for a more compact and agile feel.

| Olympus Geometry | SM | MD | LG | XL |
|---|---|---|---|---|
| Rec. Height Domestic | 5"3"-5'5" | 5'6"-5'9" | 5'10"-6'2" | 6'3"+ |
| Rec. Height International | 160-169 | 170-179 | 180-188 | 190+ |
| Seat Tube Length | 375 | 410 | 440 | 480 |
| ETT (Effective Top Tube) | 601 | 614 | 640 | 671 |
| Head Tube Angle | 65 | 65 | 65 | 65 |
| Seat Tube Angle | 76 | 77 | 77 | 77 |
| BB Drop | 61 | 61 | 61 | 61 |
| Chain Stay Length | 445 | 445 | 445 | 445 |
| Head Tube Length | 111 | 111 | 116 | 120 |
| Rake | 44 | 44 | 44 | 44 |
| Standover Height | 711 | 736 | 769 | 812 |
| Wheelbase | 1201 | 1226 | 1253 | 1285 |
| Front Center | 763 | 788 | 815 | 847 |
| Stack | 644 | 644 | 649 | 652 |
| Reach | 440 | 465 | 490 | 520 |
| Frame Weight (lbs.) | 4.2 | 4.3 | 4.4 | 4.5 |
